Product Details:
Payment & Shipping Terms:
|
| Warranty: | 1 Year | Condition: | New |
|---|---|---|---|
| Nozzle injection pressure: | ≤0.4MPa | Cleaning liquid: | Industrial Deionized Water |
| Capacity of water storage tank: | 1200cc | Plug: | 3-Pin |
| Power Supply: | AC220～240V | Outline size: | 655(L) X 560(W) X 475(H) |
| High Light: | deionized water SMT nozzle cleaner,0.4MPa SMT nozzle cleaner |
||
Machine main features
Economic benefits:
Reduce the purchase cost of suction nozzle; after using sme-24 cleaning machine, it can solve the problem of too dirty suction nozzle and scrap, so as to extend the service life.
Reduce unnecessary labor; because the machine adopts automatic cleaning, no special person is responsible for it, and the whole process is automatically completed by the machine.
It can effectively reduce the defective rate of products and improve the productivity of SMT. In the production process, a large part of it is caused by the uneven dirt on the surface of the suction nozzle and the dirt in the inner cavity, resulting in the throwing or mounting displacement, resulting in poor subsequent welding. After using the cleaning machine, the suction nozzle can always be protected in a new state, greatly improving the production efficiency.
Technical parameter:
| pressure | pressure | compressed air |
| Intake pressure setting | 0.5～0.55MPa | |
| Injection pressure setting | 0.35～0.38MPa | |
| Nozzle injection pressure | ≤0.4MPa | |
| Tube | Intake manifold | ￠12tube |
| Drain tank water pipe | ￠8tube | |
| Cleaning liquid | Cleaning liquid | Industrial deionized water |
| Liquid consumption | ≤300cc/h(5cc/min) | |
| Capacity of water storage tank | 1200cc | |
| Power Supply | Power Supply | AC220～240V |
| Plug | 3-Pin | |
| Consumption of electricity | ≤0.1Kw | |
| Environment | Working environment temperature | -5℃～ (But not frozen.) |
| Liquid temperature | 0℃～ (But not frozen.) | |
| Working environment humidity | 10～60%RH | |
| Environmental humidity of equipment | 10～60%RH | |
| dust | 0.1mg/m³(No conductive dust) | |
| Corrosive gas | Not allow | |
| Others | Outline size | 655(L) x 560(W) x 475(H) |
| Weight | (Including cleaning fluid 2000cc) |
Market
Our products had exported to more than 30 countries and regions, including South Korea, India, Vietnam, Tunisia, Egypt,Turkey, Russia, Brazil etc. And here are some of our big customers:
SURYA, POLYCAB, FIEM, RK, GK, TECHNO LED, CALCOM, ACK , KENDAL, RangDong, UNISTAR, and so on.
Our Exhibitions
Eton has participated in many exhibitions of foreign countries , such as India Mumbai Exhibition, India Delhi Exhibition, Egypt Exhibition, Turkey Exhibition, Pakistan Exhibition, etc and trading with more than 20 countries. Furthermore, we have took part in our domestic large exhibition, like Guangzhou Guangya Exhibition, Shanghai Munich Exhibition, Chongqing LED light Exhibition, etc.
Shipping and Delivery
As to the part of shipping and delivery, there are three ways for your reference, and different way is for different situations:
Land transportation: suitable for inland countries and it is affordable;
Air freight: for urgent good, and it is the most expensive transportation way;
Shipping: It’s suitable for heavy goods, and the convenience and lower cost of shipping which is easy for clients to accept the arrival time of the goods.
FAQ
Q. Is the machine easy to operate?
A. Yes, our machine is very intelligent and easy to operate, like the intelligent phone, also the software is made by our company, so we know how to make it more intelligent and operate friendly.
Q. What services can you provide?
A.
1)We provide whole line solution for our clients;
Q. Can you accept D/P or D/A as the payment term?
A. For our regular payment terms, we usually use T/T.
Q. How can I contact you to buy the goods in an efficient way?
A. Making enquiry of the products you want on the trading platform of Alibaba, Tradelink, foreign trade Express, or contact us with the social software as Whatsapp, Skype, etc.
