Roll to Roll strip making mounter HT-T9 250K with 68 nozzles pick and place machine
Machine features
① Super High-speed pick and place machine, producing with four types material at the same time with high capacity, available for 5M, 50M or any length of flexible strip and roll to roll.
② Machine functions: Picking components and mount on the PCB automatically.
③Intelligent PCB Clamping mode: Vacuum adsorption, cylinder splint, adjustable track width.
④ Exclusive patent technology :Group to take and group to mount
⑤ Dual arm four module, 17 nozzles for each mounting part, part A or part B can be mounted separately or synchronously.
⑥ High precision, Calibration automatically, available for RGB.
⑦ Easy operational program, much more convenient, automatic vision makes position fixing more accurate and convenient.
⑧Optinal :8mm,12mm,16,and 24mm automatic feeder, different nozzles and feeding way
Advantages
*Dual arm magnetic linear high-speed SMT machine.
*Producing 4 types materials at the same time.
*Vision alignment ,Mark correction.
*The mounting speed can reach 250000CPH.
*It can produce flexible light strips of any length.
*Mounting components: LED 3014/3020/3528/5050 and capacitors, resistors, bridge rectifiers.
Specification
Length | 3100mm |
Width | 2300mm |
Height | 1550mm |
Total weight | 1700kg |
PCB size | 250mm*any length |
PCB thickness | 0.5-1.5mm |
Mounting height | ≤5mm |
Mounting speed | 250000CPH |
No.of head | 68PCS |
Mounting precision | ±0.02mm |
Clients Projects
100M Strip Light SMT Production Line
ETON helped the client to plan the 100M production line, including the patch production line: PCB loader-semi-automatic printing machine-The buffer stage-high-speed pick and place machine - 24M assembly line - reflow oven - PCB unloader, and also planned 24M test line, sub-board line, coating production line. The client put into production in 2021, and the production situation is very good. ETON technicians installed the machine in the client's factory, planned the wiring, tested the production, and trained the client's engineers. The client's project was very successful, becoming one of the few in India that can provide 100M without wires. The factory for the production of all flexible light strips is very competitive, and now is planning add a new SMT production line with ETON to expand production and LED product categories.
After sales service
※ Maintenance period 1year
One year warranty, during warranty, any parts need to be repaired and replaced will be free.
※ Software and hardware lifetime maintenance
Free upgrade software, software is Reach and develop by ETON, so we support whole lifetime free upgrade updates.
※ Visit customers regularly and gather information
Visit clients regularly. We attend different exhibition in different cities every year, at the same time, we will visit local clients and support our service and collect and feedback customer suggestions in time.
※ Provide latest information about technology and equipment
We give professional technology suggestion with our clients.And share the updates news to our clients
