High speed SMT led pick and palce machine for flexible strip,LED strip making machine
High speed SMT pick and place machine for flexible strip,The HT-T7 led lamp machine is a machine designed for mounting flexible strips. HT-T7 is designed for speed improvement. It has an automatic feeding system and servo motor drive. The new 30 heads have a speed of 100000~150000CPH.lProducing with 2~4 types of materials with high capacity,available for 5m,50m or any length of flexible strip and roll to roll.and available for RGB,Extremely high placement accuracy.
Features
Improved Productivity
HT-T7 LED lamp machine,Applying the exclusive patented technology of group-based and group-based pasting, the pasting speed is 100000-150000 CPH, 60 feeders station and 30 nozzles. It can automatically transmit on-line. And It can produce 2-4 kinds of materials at the same time, which greatly improves the efficiency.
Improved Usability
HT-T7 led bulb laser printing machine,available for 5m,50m or any length of flexible strip and roll to roll.and available for RGB,mounting components about LED 3014/3020/3528/5050 and resistors,capacitors ,bridge rectifiers.
Reach 0.02mm placing accuracy
By improving pick and place machine rigidity and further refining its independent servo control and vision recognition technology,5 sets of imported camera are equipped with visual alignment, mark correction technology and optical positioning technology to accurately identify the position of PCB board and quickly and accurately mount components.
Strong durability
The quality of hardware equipment is guaranteed by certificate, the quality of dual motor electronic flying and guide rail and screw is guaranteed, which can support 24-hour operation.
Simple operation
Windows 7 system can be used to switch the Chinese-English interface, usually 3 to 5 days training of operation is enough.
Technical parameter
| HT-T7 led pick and place machine |
| PCB |
PCB length width |
250mm*any length |
| PCB thickness |
0.5~1.5mm |
| PCB clamping |
Adjustable pressure pneumatic |
| Mounting mode |
Group to take and group to mount |
| O.S. |
system |
Windows 7 |
| software |
R&D independently |
| display |
LED monitor |
| Input device |
Keyboard , mouse |
|
Vision
system
|
No.of camera |
5 sets of imported camera
Vision alignment,mark correction
|
| Mounting precision |
0.02mm(repeat precision) |
| Mounting height |
<15mm |
| Mounting speed |
100000~150000CPH |
| Components |
LED 3014/3020/3528/5050 and resistors,capacitors ,bridge rectifiers. |
| Components space |
0.2mm |
| No.of feeders station |
60PCS |
| No.of nozzles |
30PCS |
| Power |
220AC 50HZ |
| Power consumption |
5KW |
| Transmission speed |
>500mm/sec |
| Transmission direction |
Single (left to right or right or left) |
| Position mode |
Optical |
| X,Y,X axis drive way |
Servo motor control for X,Y,Z axis |
| Feeding way |
Electric feeder with double motor |
Packaging & Delivery
Our mode of transportation including water, land and air transportation.You can choose the most suitable way according to your requirements.
Our packing is made of wooden box with vacuum package, and we promise to deliver the goods within four weeks after payment.
Honour show
ETON advanced technology and innovation drives the revolution of market rapidly ,and obtains a number of intellectual property technologies.
Including 9 invention patents,112practical patents,12 software copyrights.
Attention
1. Before using the Pick and Place machine, you must understand the basic parameters of the placement machine;
2. Before running the Pick and Place machine, the operator should do a comprehensive inspection of the machine.
3. According to the boot operation sequence to implement the Pick and Place machine, there must have a detailed machine operation instructions;
4. It is necessary to conduct regular troubleshooting and maintenance work on the Pick and Place machine in a timely manner.
Our Partners
ETON advanced technology and innovation drives the revolution of market rapidly,and obtains a number of intellectual property technologies,including 9 invention patents,112 practical patents ,12 software copyrights,which save much labors and space of production ,got large market share in USA ,KOREA,INDIA,GERMANY,EGYPT,TURKEY,VIETNAM,TUNISIA,THAILAND more than 20 countries.
Remarks:
1.Payment terms: Deposit 30% in advance,the balance 70% should be paid before shipment by T/T.
2.Delivery time: 30 days after deposit.
3.Warranty: 1 year.(including spare parts)
FAQ
1, What’s the terms of payment? What about the trade term?
T/T is OK. You can choose FOB Shenzhen.
2, What is the delivery date?
We will deliver the goods after 30 days' deposit.
3, What mode of transport does the goods adopt?
Our mode of transportation is very flexible.Our mode of transportation including water, land and air transportation.You can choose the most suitable way according to your requirements.
4, What is the direction of transmission of machines?
The transmission direction of this machine is single direction.From left to right or from right to left.
5, How about your operating system?
The operating system is Windows 7. The software is developed independently. It supports Chinese and English operation interface. And It has simple structure and is easy to operate.
