Dual purpose professional high speed mounter ,the capacity reach 170000CPH
HT-XF is a special machine for mounting hard and soft strips,mounting components about LED 3014/3020/3528/5050 and resistors,capacitors ,bridge rectifiers.Dual purpose professional high speed mounter ,the capacity reach 170000CPH. 17 nozzles for each mounting module part A or B can be mounted separately or synchronously.
Advantages
1. Vision system: vision alignment ,mark correction with 5 sets of imported camera.
2. Dual module professional mounter,17 nozzles for each mounting module.
3. Fully automatic feeder feeding system to ensure the accuracy of placement speed machine placement machine.
4. XYZ axis by servo motor to drive ,Ensure that the machine can run at high speed for 24 hours.
Performance introduction
| High Speed and High Precision |
This special Mounter has a speed of 150000~170000 CPH.Can save space, labor costs, management costs
No. Of feeder station:34PCS nozzles:34PCS
|
|
Good durability
|
Using High Stability Electronic Dual Motor
The wear resistance of screw rod is not easy to deviate and has high accuracy.
The guide rail has strong bearing capacity and high stability.
High-quality hardware configuration for 24-hour machine operation.
|
| auto-adjust |
Automatic adjustment of the guide rails to improve work efficiency and portability without manual
According to the thickness of the board, it can automatically adjust the height of the top board to ensure the flatness of the PCB board.
|
| Easy to operate |
Simple programming, easy to understand and easy to learn, with independent research and development software, free upgrade forever, professional installation and training
|
| HT-XF | ||
| PCB | PCB length width | Max:330*1200mm min:90*330mm |
| PCB thickness | 0.5~5mm | |
| PCB clamping | Adjustable pressure pneumatic | |
| Mounting mode | Group to take and group to mount | |
| O.S. | system | Windows 7 |
| software | R&D independently | |
| display | LED monitor | |
| Input device | Keyboard , mouse | |
|
Vision system |
No.of camera |
5 sets of imported camera Vision alignment,mark correction |
| Mounting precision | 0.02mm(repeat precision) | |
| Mounting height | <15mm | |
| Mounting speed | 150000~170000CPH | |
| Components | LED 3014/3020/3528/5050 and resistors,capacitors ,bridge rectifiers. | |
| Components space | 0.2mm | |
| No.of feeders station | 34PCS | |
| No.of nozzles | 34PCS | |
| Power | 220AC 50HZ | |
| Power consumption | 5KW | |
| Conveyor transmission | Max length:1200mm | |
| Transmission speed | >500mm/sec | |
| Transmission direction | Single (left to right or right or left) | |
| Transmission mode | Auto online drive | |
| Position mode | Optical | |
| Air pressure | >5.0kg /cm² | |
| Electrical control | Independent research and development by ETON | |
| Motion control card module 1set | Independent research and development by ETON | |
| X,Y,X axis drive way | Servo motor control for X,Y,Z axis | |
| Feeding way | Electric feeder with double motor | |
Shenzhen ETON Automation Equipment Co. LTD. is a leading manufacturer of automatic high-speed pick and place machine focusing on “High efficiency Low consumption” in the word.ETON has created superior value for customers as the outstanding worldwide brand of high speed SMT machine with good reputation .looking forward to the future ,we believe that ETON will seek to better achievement in SMT field and make greater contributions to the industry and society.
Logistics and delivery
Our mode of transportation including water, land and air transportation.You can choose the most suitable way according to your requirements.
Our packing is made of wooden box with vacuum package, and we promise to deliver the goods within four weeks after payment.
Honour show
ETON advanced technology and innovation drives the revolution of market rapidly ,and obtains a number of intellectual property technologies.
Including 9 invention patents,112practical patents,12 software copyrights.
Our Cooperators
We have many excellent overseas customers and maintain long-term cooperative relationship. Customers are very satisfied with our products.
Before services
1) Professional sales manager of LED SMT machine, provide professional suggestion and service to you !
2) 24 hours online service and technical support, solve your questions quickly!
3) Sound company organization and working system, guarantee you a fast delivery!
4) Design and provide the whole SMT processing lines for you based on your budget , workshop covering area with best prices!
After-sale Service
we will send our engineer to your factory to install machine and training freely.
We have service office in india,and have indian engineer in delhi and mumbai.Can support quickly.
Standard warranty is one year,during warranty,any parts need to be repaired and replaced will be free.
Remarks
1.Payment terms: Deposit 30% in advance,the balance 70% should be paid before shipment by T/T.
2.Delivery time: 30 days after deposit.
3.Warranty: 1 year.(including spare parts)
1. What’s the terms of payment? What about the trade term?
T/T is OK. You can choose FOB Shenzhen.
2. What is the delivery date?
We will deliver the goods after 30 days' deposit.
3. What mode of transport does the goods adopt?
Our mode of transportation is very flexible.Our mode of transportation including water, land and air transportation.You can choose the most suitable way according to your requirements.
4. What is the direction of transmission of machines?
The transmission direction of this machine is single direction.From left to right or from right to left.
5. How about your operating system?
The operating system is Windows 7. The software is developed independently. It supports Chinese and English operation interface. And It has simple structure and is easy to operate.
