Product Details:
Payment & Shipping Terms:
|
| Condition: | New | Name: | Solder Paste Mixer |
|---|---|---|---|
| Product Name: | Solder Paste Mixer | Usage: | LED SMT SMD |
| Application: | SMT Assembly Production Line | Item: | SMT Machine |
| High Light: | led chip making machine,led production equipment |
||
The features of solder paste mixer
1. 0 maximum speed can reach 1000 rpm
1.1 When stirring, it is necessary to de-ice the solder paste beforehand;
1.2 do not have to open the container;
1.3 power single phase 220v:
1.4 No gas problem:
1.5 does not destroy the shape of tin powder:
1.6 fixtures are suitable for all kinds of 500g packaging solder paste cans;
1.7 mixing time can be set arbitrarily;
1.8 has manual speed control function
The parameters of solder paste mixer
| Dimension | 400x400x420mm |
| Weight | About 35KG |
| Operating Voltage | AC 220V 50Hz 60Hz >60W |
| Operating speed | Motor 1350 RPM revolution: 1000RPM Rotation: 500PRM |
| Working capacity | 500 g. Syringe, red plastic tube, etc. the fixture can be customized. |
| Stir two cans of solder paste at the same time | 500g |
| Stiring time | 1-99 minute digitally adjustable |
| Operation method | Light touch button for easy operation |
| Fixture function | Universal fixture for all kinds of brand solder paste cans |
| Running noise | Low running noise <20dB |
Solder paste mixer installation and commissioning
2.1 Installation
2.1.1 Place the machine on a level stable table or floor and adjust the four feet of the machine. Keep
the cup to the level to avoid abnormal sound or shaking when the machine is stirring at high speed:
2.1.2 Please check the operating voltage specification (Ac220v) of the machine and the voltage
specification of the mains Match, turn on the single-phase 220v power supply;
2.1.3 Please confirm whether there is loose screw, the machine inside the machine must not have
foreign objects, avoid sending Collision.
2.2 Debugging
2.2.1 Confirm that the machine is placed smoothly.
2.2.2 Place the solder paste jar to be stirred completely in the fixture of the machine. Mix two cans
at the same time 500G solder paste can.
2.2.3 Please turn the solder paste can by hand to confirm that there will be no collision. Cover the
cover and turn on the power switch.
2.2.4 Adjust the panel time Set the time to the better stirring time, about 3-5 minutes. Depending
on the solder paste brand and solder paste at the time.
2.2.5 After pressing the start switch, the running indicator lights. The machine starts to automatically
stir at high speed, When the machine is finished, the machine will stop automatically, and the unit
will automatically cut off the power when the cover is opened.
2.2.6 After the operation is completed, the operation stops and the display shows the actual mixing time.
2.2.7 In order to stop the machine running during operation, press the power switch key to stop and cancel
the operation.
