Product Details:

Place of Origin:	china
Brand Name:	eton
Certification:	ccc,ce,sira
Model Number:	ht-t9
Document:	Product Brochure PDF

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Price:	$ 95,000 /unit
Packaging Details:	Waterproof material packing and wooden case
Delivery Time:	30 work days
Payment Terms:	L/C, T/T
Supply Ability:	80 units per months

Contact Now

Detailed Product Description

Pcb Size:	250mm*any Length	Pcb Clamp;ing:	Adjustable Pressure Pneumatic
System:	Windows7	Software:	R&d Independently
Display:	Touch Screen Monitor	Input Device:	Keyboard,mouse
No. Of Camera:	5	POWER:	380AC 50HZ
Power Consmption:	6kw	Mounting Mode:	Group Of Group Of Stick
Components Space:	0.2mm	Feeders Stations:	64PCS
Nozzles:	64PCS	Mounting Speed:	200000CPH
Mounting Height:	13mm

1.product details

Components: LED3014/3020/3528/5050 and resistor,capacitors,bridge rectifiers,etc.

Application:5m,50m or any length of flexible strip and roll to roll;RGB

pick and place machine for led,smt pick and place ,automatic pick and place,magnetic linear motor high speed mounter 0

2.product Technical parameters of high speed pick and place machine

Model number	HT-T9
Dimension	245021001550mm
PCB size	250mm*any length
PCB thickness	0.5～1.5mm
PCB clamping	adjustable pressure pneumatic
mounting mode	group to take and group to mount
system	windows 7
display	touch screen monitor
input device	keyboard,mouse
NO.of camera	5 sets of imported camera
mounting precision	±0.02mm
mounting height	<13mm
mounting speed	200000CPH
components space	0.2mm
NO.of feedings station	64pcs
NO.of nozzles	64pcs
power	380AC 50HZ
power consumption	6KW
operating environment	23℃±3℃
conveyor transmission	any length
transmission speed	>500mm/sec
transmission direction	single(left→right,right→left)
transmission mode	online drive
position mode	optical
Air Force	0.5mpa
electrical control	independent research and development by ETON
motion control card module 1set	independent research and development by ETON
X.Y axis drive way	high-end magnetic linear motor+servo motor
feeding way	electric feeder with double motor

2.product features of smt pick and place machine

X,Y,Z drive way is high-end magnetic linear motor+servo motor.
Install 5 camera and adopt vision for the flight identification, mark correction.
PCB clamping is electric clamping+adjustable pressure pneumatic.
Vision for the flight identification ,mark correction.
Electronic feeder feeding system.
Non-stop material re-loading function.
Auto-optimization after coordinates generated.

pick and place machine for led,smt pick and place ,automatic pick and place,magnetic linear motor high speed mounter 2

2Packing & shipping of smt mounter machine

Packaging materials	Waterproof material and wooden case
Lead time	Delivery within 30 days after receipt of payment..
port	Shenzhen
Delivery time	Transshipment and partial shipment according to the contract

pick and place machine for led,smt pick and place ,automatic pick and place,magnetic linear motor high speed mounter 3

6.Company profile

pick and place machine for led,smt pick and place ,automatic pick and place,magnetic linear motor high speed mounter 4

pick and place machine for led,smt pick and place ,automatic pick and place,magnetic linear motor high speed mounter 5

pick and place machine for led,smt pick and place ,automatic pick and place,magnetic linear motor high speed mounter 6

pick and place machine for led,smt pick and place ,automatic pick and place,magnetic linear motor high speed mounter 7

7.Our clients

8.FAQ
pick and place machine for led,smt pick and place ,automatic pick and place,magnetic linear motor high speed mounter 9

pick and place machine for led,smt pick and place ,automatic pick and place,magnetic linear motor high speed mounter 10

SMT mount cycle

mount cycle is the most basic parameter for marking mount speed. it refers to the time used when picking up components, after detection, sticking to the PCB and then returning the pick up component position. For each trip, complete a mount operation, that is, a mount cycle. The mounting period of Chip components is less than 0.2 s. At present, the maximum mounting period is 0.06-0.03 s;- and the mounting period of machine mounting QFP is 1~2.

Selection of Surface Mounting Components

selection and design of surface mounted components is a key part of the overall design of the product. the designer determines the electrical properties and functions of the components in the system structure and detailed circuit design stage. the packaging form and structure of surface assembled components should be determined in the SMT design stage according to the specific conditions of the equipment and process and the overall design requirements. solder joints installed on the surface are both mechanical and electrical connection points, and reasonable selection has a decisive effect on improving PCB design density, productivity, testability and reliability.

There is no difference in function between surface mounted components and plug-in components, the difference lies in the packaging of components. Choose the appropriate package, the main advantages are :1). effectively saving PCB area ;2). provide better electrical properties ;3). protect the interior of the components from environmental effects such as moisture ;4). provide good communication links ;5). help dissipate heat and facilitate transmission and testing.
