Product Details:

Place of Origin:	china
Brand Name:	eton
Certification:	ccc,ce,sira
Model Number:	ht-f8
Document:	Product Brochure PDF

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Price:	$70,000.00/unit
Packaging Details:	Waterproof material packing and wooden case
Delivery Time:	30 work days
Payment Terms:	L/C, T/T
Supply Ability:	80 units per months

Contact Now

Detailed Product Description

Pcb Size:	80110mm~345600mm	Pcb Clamp;ing:	Adjustable Pressure Pneumatic
System:	Windows7	Software:	R&d Independently
Display:	Touch Screen Monitor	Input Device:	Keyboard,mouse
No. Of Camera:	5	POWER:	380AC 50HZ
Power Consmption:	5kw	Mounting Mode:	Group To Take And Group To Mount
Components Space:	0.2mm	Feeders Stations:	32PCS
Nozzles:	32PCS	Mounting Speed:	150000CPH
Mounting Height:	15mm

1.product details

Components: LED2121/2727/3528/5050 and resistor,capacitors,bridge rectifiers,etc.

Application:LED display

smd mounting machine high speed pick and place mounter,smt pick and place ,automatic mounter,magnetic linear motor 0

2.product Technical parameters of high speed pick and place machine

Model number	HT-F8
Dimension	160019001550mm
PCB size	80110～345600mm
PCB thickness	0.5～5mm
mounting mode	group to take and group to mount
system	windows 7
display	LED monitor
input device	keyboard,mouse
NO.of camera	5 sets of imported camera
mounting precision	±0.02mm
mounting height	<15mm
mounting speed	150000CPH
components space	0.2mm
NO.of feedings station	32pcs
NO.of nozzles	32pcs
power	220AC 50HZ
power consumption	5KW
operating environment	23℃±3℃
conveyor transmission	MAX length:1200mm
transmission speed	>500mm/sec
transmission direction	single(left→right,right→left)
transmission mode	Auto online drive
position mode	optical
air pressure	>5.0kg/c㎡
electrical control	independent research and development by ETON
motion control card module 1set	independent research and development by ETON
X.Y axis drive way	servo motor
feeding way	electric feeder with double motor

3.product features of smt pick and place machine

X,Y,Z drive way is high-end magnetic linear motor+servo motor.
PCB clamping is adjustable pressure pneumatic.
Vision for the flight identification ,mark correction.
Electronic feeder feeding system.
Non-stop material re-loading function.
Auto-optimization after coordinates generated.

smd mounting machine high speed pick and place mounter,smt pick and place ,automatic mounter,magnetic linear motor 2

4.Packing & shipping of smt mounter machine

Packaging materials	Waterproof material and wooden case
Lead time	Delivery within 30 days after receipt of payment..
port	Shenzhen
Delivery time	Transshipment and partial shipment according to the contract

smd mounting machine high speed pick and place mounter,smt pick and place ,automatic mounter,magnetic linear motor 3

5.Company profile

smd mounting machine high speed pick and place mounter,smt pick and place ,automatic mounter,magnetic linear motor 4

smd mounting machine high speed pick and place mounter,smt pick and place ,automatic mounter,magnetic linear motor 5

smd mounting machine high speed pick and place mounter,smt pick and place ,automatic mounter,magnetic linear motor 6

smd mounting machine high speed pick and place mounter,smt pick and place ,automatic mounter,magnetic linear motor 7

6.Our Our certificates and certifications

smd mounting machine high speed pick and place mounter,smt pick and place ,automatic mounter,magnetic linear motor 8

7.our services

8. trade show

smd mounting machine high speed pick and place mounter,smt pick and place ,automatic mounter,magnetic linear motor 10

smd mounting machine high speed pick and place mounter,smt pick and place ,automatic mounter,magnetic linear motor 11

Visual alignment, MARK correction

Based on the image information read by the camera, the XYZ movement required for positioning is automatically calculated, and then the XYZ correction of the workpiece is realized by controlling the movement of a three-axis platform (or four-axis platform), so as to achieve the purpose of accurate alignment. Usually used in on-line production or production line automation of the situation.

To adapt to different components and improve the accuracy and speed of the visual system, the detection pair camera is designed as a camera with high resolution in small field for small Chip components CCD1 and a camera with low resolution in large field for large IC as a reference positioning (MARK point search) camera. When the center of the suction nozzle reaches the center position of the visual field of the middle camera of the detection pair, a trigger signal is issued to obtain the image, and the corresponding light source shines once at the same time as the trigger.
