| Pcb Size: | 100*100mm~500*300mm | Pcb Clamp;ing: | Adjustable Pressure Pneumatic |
|---|---|---|---|
| System: | Windows7 | Software: | R&d Independently |
| Display: | Touch Screen Monitor | Input Device: | Keyboard,mouse |
| No. Of Camera: | 4 | POWER: | 380AC 50HZ |
| Power Consmption: | 8kw | Mounting Mode: | Group Take Cent Stick, Cent Take Cent Stick. |
| Components Space: | 0.2mm | Feeders Stations: | 60PCS |
| Nozzles: | 16PCS | Mounting Speed: | 80000CPH |
| Mounting Height: | 40mm | ||
| High Light: | Bulb Light Smt Mounter Machine,LED Display Smt Mounter Machine |
||
product details
HT-E5D machine is Dual system,dual module multifunctional mounter with high capacity of 80000CPH. It can mount capacitors,resistors,LED3014/3020/3528/5050,IC and shaped components. It applies to power driver,electric board,lens,linear bulb,household appliance and etc.
product Technical parameters of high speed pick and place machine
| Place of origin | Guangdong,China |
| Model number | HT-E5D |
| dimension | 1650*2000*1550 |
| PCB size | 100*100～500*300 |
| PCB thickness | 0.5～3mm |
| components | LED,capacitors,resistors,shaped components,etc. |
| Mounting speed | 80000CPH |
| Mounting mode | Group picking and separate placing, separate picking and separate placing. |
| Mounting precision | ±0.02cm |
| Feeder stations | 60pcs |
| nozzles | 16pcs |
