Product Details:
Place of Origin: CHINA
Brand Name: ETON
Model Number: HT-T9
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: EXW USD 95000/sets
Packaging Details: Our packing is made of wooden box with vacuum package, and we promise to deliver the goods within four weeks after payment.
Delivery Time: 30 days after deposit
Payment Terms: T/T
Supply Ability: 50 sets per mouth
Detailed Product Description
Name: SMT Mounting Machine Feeders: 64 PCS
Nozzles: 64 PCS Components: LED 3014/3020/3528/5050 Resistor Capacitors
Display: Touch Screen Monitor Power: 380V
Camera: 5 PCS Position: Optical
High Light:

200000CPH SMT Mounting Machine

,

KW SMT Mounting Machine

,

Led Chips Smt Mounter Machine

Mark correction servo motor SMT Mounitng machine for led chips







Servo Motor 200000CPH 6KW SMT Mounting Machine For Led Chips 0
HT-T9
PCB PCB length width 250mm*any length
PCB thickness 0.5~1.5mm
PCB clamping Adjustable pressure pneumatic
Mounting mode Group to take and group to mount
O.S. system Windows 7
software R&D independently
display LED monitor
Input device Keyboard , mouse

Vision

system

No.of camera

5 sets of imported camera

Vision alignment,mark correction

Mounting precision 0.02mm(repeat precision)
Mounting height <5mm
Mounting speed 200000CPH
Components LED 3014/3020/3528/5050 and resistors,capacitors ,bridge rectifiers.
Components space 0.5mm
No.of feeders station 68PCS
No.of nozzles 68PCS
Power 380AC 50HZ
Power consumption 6KW
Conveyor transmission Belt drive
Transmission speed >500mm/sec
Transmission direction Single (left to right or right or left)
Transmission mode Auto online drive
Position mode Optical
Air pressure >5.0kg /cm²
Electrical control Independent research and development by ETON
Motion control card module 1set Independent research and development by ETON
X,Y,X axis drive way Servo motor + High-end magnetic linear
Feeding way Electric feeder with double motor





Features
T9 SMT mounting machine Producing with 4 types of materials with high capacity,available for 5m,50m or any length of flexible strip and roll to roll.
T9 pick and place machine with Dual arm four module,17 nozzles for each mounting part ,part A or part B can be mounted separatly or synchronously.
T9 pick and palce machine:Calibration automatically,high precision,available for RGB.
Exclusive patent technology :group to pick and group to mount.



What is SMT production process?

(1)Solder Paste Printing
After the solder paste is refluxed and stirred, a small amount of solder paste is placed on the stencil printer. Operate the stencil printer to print the solder paste onto the PCB.
(2)Mounting part
The PCB board that has been brushed with solder paste will be sent to the pick and place machine for automatic mounting, and the pick and place machine will automatically take components and paste it.
(3)reflow soldering
The PCB board be mounted with components is sent to reflow oven, and the reflow oven will be fixed automatically to get PCBA.
(4)Testing
Check whether the PCBA is misaligned or leaking.



Servo Motor 200000CPH 6KW SMT Mounting Machine For Led Chips 1



Packaging & Delivery
Our mode of transportation including water, land and air transportation.You can choose the most suitable way according to your requirements.

Our packing is made of wooden box with vacuum package, and we promise to deliver the goods within four weeks after payment.

Packing method:
1)Standard box package for light and small item;

2)Strong wood package for heavy and large equipment;

Packing Details :Plywood case, for export!
Port:Shenzhen
Delivery Details : 25-30days



Logistics and delivery
Our mode of transportation including water, land and air transportation.You can choose the most suitable way according to your requirements.
Our packing is made of wooden box with vacuum package, and we promise to deliver the goods within four weeks after payment.



FAQ

1.What kind of driving mode does the XYZ axis adopt?

X axis is magnetic liner motor,Y axis and Z axis is servo motor,very good performance and high accuracy.

2.What type of transportation can be used?

Our modes of transportation are flexible, and we can choose both sea, land and air transportation.

3.Is your software interface in English?

English interface and Chinese interface are both available.

4.What’s the terms of payment? What about the trade term?

T/T is OK. You can choose FOB Shenzhen.

5.How is your service?

If you buy our machine,we will send our engineer to your factory to install machine and training freely.
