| Name: | Pick And Place Machine | Components: | LED 3014/3020/3528/5050 Resistor Capacitors |
|---|---|---|---|
| PCB Size: | 1200*350mm | Nozzles: | 68 PCS |
| Warranty: | 1 Year | Speed: | 200000CPH |
| Total Weight: | 1500kg | Feeders: | 34 PCS |
| High Light: | 6KW Led Pick And Place Machine,Led Pick And Place Machine 200000CPH,LED 5050 SMT Mounter Machine |
||
5050 0201 led high speed pick and place machine price SMT mounitng machine
Advantages
1.Vision system: vision alignment ,mark correction with 5 sets of imported camera.
2.Dual module professional mounter,17 nozzles for each mounting module.
3.Fully automatic feeder feeding system to ensure the accuracy of placement speed machine placement machine.
4.XYZ axis by servo motor to drive ,Ensure that the machine can run at high speed for 24 hours.
Performance introduction
Easy to operate
Simple programming, easy to understand and easy to learn, with independent research and development software, free upgrade forever, professional installation and training
Special LED mounter
apply to the 0.6m,0.9m.102mLED rigid PCB and0.5m,1m flexible strip.
Visual system
5 sets of imported camera
Vision alignment ,mark correction
The imported camera can accurately identify the exact position of PCB board and the position of components and board. The overlooking camera searches for the target on the circuit board (as a benchmark) in order to place the circuit board in the correct position before assembly, and the overlooking camera is used to detect elements in the fixed position.
High Speed and High Precision
This special Mounter has a speed of 200000 CPH.Can save space, labor costs, management costs
Technical parameter
| HT-X9 | ||
| PCB | PCB length width | Max:350*1200mm min100*100mm |
| PCB thickness | 0.5~5mm | |
| PCB clamping | Adjustable pressure pneumatic | |
| Mounting mode | Group to take and group to mount | |
| O.S. | system | Windows 7 |
| software | R&D independently | |
| display | LED monitor | |
| Input device | Keyboard , mouse | |
|
Vision system |
No.of camera |
5 sets of imported camera Vision alignment,mark correction |
| Mounting precision | 0.02mm(repeat precision) | |
| Mounting height | <15mm | |
| Mounting speed | 200000CPH | |
| Components | LED 3014/3020/3528/5050 and resistors,capacitors ,bridge rectifiers. | |
| Components space | 0.2mm | |
| No.of feeders station | 34PCS | |
| No.of nozzles | 68PCS | |
| Power | 220AC 50HZ | |
| Power consumption | 6KW | |
| Conveyor transmission | Max length:1200mm | |
| Transmission speed | >500mm/sec | |
| Transmission direction | Single (left to right or right or left) | |
| Transmission mode | Auto online drive | |
| Position mode | Optical | |
| Air pressure | >5.0kg /cm² | |
| Electrical control | Independent research and development by ETON | |
| Motion control card module 1set | Independent research and development by ETON | |
| X,Y,X axis drive way | Servo motor+linear magnetic motor | |
| Feeding way | Electric feeder with double motor | |
