RT-4 LED Four Module SMT Mounting Machine 16KW PCB Smt Assembly

RT-4 Automatic LED Four-module SMT mountering machine / PCB smt assembly pick and place machine

Features:

1. The four-module magnetic levitation linear multifunctional placement machine adopts high-end magnetic levitation linear motor + servo motor, which greatly improves the accuracy and stability of the placement machine, and also greatly reduces the noise during the placement process.

2. The four modules can produce four different products at the same time, which greatly saves manpower, material resources and production time, improves the mounting efficiency, and the production capacity reaches 120,000 to 140,000 CPH.

3. It has 80 paper feeders and 40 suction nozzles, and the mounting method is group picking and separate piacing, separate picking and separate placing. Each mounting head is controlled by an independent motor and can be mounted at different angles Components at the same time.

4. 8 sets of high-speed synchronous recognition cameras can simultaneously perform visual correction on 40 placement heads to absorb different electronic components. The machine also has an automatic replenishment function.

5. The two modules on the same side can be installed with two different materials, for example, the first module is installed with lamp beads, the second module is installed with various special-shaped components, etc., which can save the installation time of the PCB board. Improve work efficiency.

6. The XY axis moving mechanism adopts high-precision grinding ball screw + servo motor, which has high precision, long life and low wear.

7.High-performance adaptability, accuracy is controlled at the level of plus or minus 0.04mm.

8. Intelligent automatic programming: The operation is simple and convenient, which greatly saves the time of editing process files and improves work efficiency.

9. Dual-motor electronic feeder, stable feeding, no need for repeated calibration.

Technical parameter:

1.Dimension:

2.PCB:

3.Mounting Components:

4.Machine structure and capacity:

Application:

1. Installation components: LEDs, capacitors, resistors, ICs, special-shaped components, etc.

2. Installation products: DOB, bulb light, downlight, panel light, street light, power supply, circuit board, driver, household appliance control panel, etc.
