Product Name: | Pick And Place Machine | Models: | HT-E8S-1200 |
---|---|---|---|
Max Pcb Size: | 1200*100mm | No. Of Nozzle: | 12 Heads |
Optimal Speed: | 45000CPH | Feeding Way: | Electric Feeder With Double Motor |
Highlight: | 45000 CPH LED Bulb Assembling Machine,12heads LED Bulb Assembling Machine,45000 CPH LED Light Making Machine |
Wide Applicability 45000 CPH LED Bulb Assembling Machine With 12 Heads
Wide applicability 1.2m multi-function pick and place machine with 12heads
A brief introduction to the pick and place machine:
Used in SMT production lines, widely used in lighting, display screens, power supplies, home appliances, new energy, communications and other industries. The placement machine is mainly used for printing and printing after the printing machine, and the PCB board with solder paste is printed on the PCB board for component placement.
Features
Vision alignment flight identification,mark correction
Auto-optimization after coordinates generated
Apply to different kinds of SMD components: LED chip, capacitors, resistors, IC,RGB, shaped components,etc.
Component : Min.size 0402 Max.height 15mm
Parameter
HT-E8S Technical Parameter |
||
1 |
Length*Width*Height |
2550mm*1650mm *1550mm |
2 |
Total Weight |
1700kg |
3 |
PCB Length Width |
Max:1200*350mm Min:100*100mm |
4 |
PCB Thickness |
0.5-5mm |
5 |
PCB Clamping |
Adjustable pressure pneumatic |
6 |
Mounting Mode |
Group picking and separate placing,separate picking and separate placing |
7 |
Software |
R&D independently |
8 |
Display |
Touch screen |
9 |
Input Device |
Keyboard,Mouse |
10 |
No. of Camera |
2 sets of imported camera |
11 |
Position Camera |
Vision for the flight identification + MARK correction |
12 |
Mounting repeat Precision |
±0.04mm chip |
13 |
Mounting Height |
<15mm |
14 |
Mounting Speed |
45000 CPH(optimum) |
15 |
Components |
LED chip,capacitors,resistors,IC,RGB,shaped components etc. |
APPLICATION: Apply to the DOB,bulbs,flexible strip,tube,tube,display,electric board,
all kinds of driver,etc. 8 nozzles working at the same time,high productivity.
SMT solution
ETON over 10 years experience in SMT machines, so we are very professional to provide whole line solution.
Automatic stencil printer machine with pick and place machine, loader, conveyor, unloader, reflow oven to be one automatic line.
Automatic line save much labor cost compared with the semiautomatic line, also with higher printing precision could produce high quality electrical products. Here are the automatic SMT line solution layout:
What is the company advantage?
* 10 years of SMT manufacturing and LED market experience;
* Industrial park: 5000 square meters, workshop: 45000 square meters;
* The assembly, powder spraying and sheet metal of the machine are all manufactured by ourselves;
* There is an independent R&D team with nearly 50 people;
* The company has more than 300 employees;
* With overseas offices and local full-time engineers, such as Egypt, India, etc.
FAQ
Q1: What is your machine actual speed? A1: The actual speed is influenced by many factors, such as the number of the components, the kind of products, the time of send board, etc. So we can’t give you the accurate actual production capacity. Such as for RT-1, the speed of led chip mainly around 23000-25000CPH. But for driver will be different. Q2: Does the price include spare parts(nozzle and feeder)? A2: Different client has different requirements on spare parts, it is not fair to clients to add in equivalent price for spare parts, so we don’t add the spare parts on price. And price is only for machine. Q3: Can you support whole SMT line? A3: Yes, we can provide whole line solution if you want. We are very professional on SMT field. Q4: What is your machines quality? A4: We have our own industrial park. There are production centre and R&D centre and quality inspection centre to guarantee the machine quality.
