| PCB Length Width: | 250mm*any Length | PCB Clamping: | Vacuum Adsorption, Cylinder Splint, Adjustable Track Width |
|---|---|---|---|
| No.of Camera: | 5 Sets | No.of Nozzles: | 34PCS |
| Warranty: | 1 Year | Mounting Speed: | 150000-180000CPH |
| Feeders Station: | 68PCS | Pcb Thickness: | 0.5-1.5mm |
| High Light: | Full Automatic Flexible Strip Mounting Machine,34 Heads Flexible Strip Mounting Machine,Pick And Place Machine 180000CPH |
||
Full-Automatic for any length of flexible strip with 34 Heads Pick And Place Machine
1. Introduction of product
Dual-arm professional high-speed mounter, 2-4 types of materials capacity reach 180000CPH.
Apply to the 0.6m, 0.9m, 1.2m rigid PCB and 0.5m,1m LED flexible strip. Producing with 2-4 types of materials with high capacity, available for board with any proportion of LED chip and resistor.
It has 5 sets cameras to work.(vision alignment, mark correction)
Can be mounted include LED 3014/3020/3528/5050 and resistors, capacitors, bridge rectifiers .
Machine System is independent research and development by ETON.
2. Features
Apply to the 0.6m, 0.9m, 1.2m rigid PCB and 0.5m,1m LED flexible strip. Producing with 2-4 types of materials with high capacity, available for board with any proportion of LED chip and resistor.
Two mounting module, 17 nozzles for each mounting part, part A or part B can be mounted separately or synchronously.
Calibration automatically, high precision, available for RGB.
Exclusive patent technology:group to take and group to mount.
The speed can reach 180000CPH.
Vision alignment, mark correction.
3. Machine parameter
| F7S | ||
| PCB | PCB length width | Max:1200*330mm Min:100*100mm |
| PCB thickness | 0.5-5mm | |
| PCB clamping | Adjustable pressure pneumatic | |
| Mounting mode | Group picking and group placing | |
| Vision system | No.of camera |
5 sets Vision alignment, mark correction |
| No.of feeder station | 68PCS | |
| No.of nozzles | 34PCS | |
| Mounting height | ≤5mm | |
| components | LED3014/3020/3528/5050 and resistor, capacitors, bridge rectifiers, etc. | |
4. Product application
5. Company introduction, exhibition, certificate
6. Package and delivery
Shipping Way:
※ By air, for sample and small package
※ By sea, for large package and quantity;
※ Other ways as customer requested.
7. Service
Pre-sale service
Provide suitable production plan
Advise on plant electrical equipment and layout
Sale service
Report machine status in time
Follow up and send test machine video
After-sales service
Engineers can arrive on site to teach operation and debug the machine
24 hours to deal with problems online, arrange engineers to solve problems
Software lifetime upgrade
Regular visit (one year warranty period, spare parts repair free; Once or twice a year after warranty)
8. FAQ
1) Do you have oversea after sale service?
Yes ,We can provide technical support abroad. If you have any technical problems, our engineers will provide you with timely support. Abroad, we have India, Turkey and Egypt office and local engineer, etc.
2) How is the transportation?
By sea, by air and land transportation.
3) It’s hard to use the machine?
Machine is very intelligent and easy to operate, like the intelligent phone, also the software is made by our company. About 3-5 days you can operate.
4) What machine can I buy from you?
We can provide a product line of SMT. Such as Multi-function placement machine, high-speed placement machine, dispensing machine, loading machine, printing machine, reflow soldering, etc.
5)Do you have any customers in India?
Yes, we have many big clients in India, Turkey, Egypt and others.
