Automatic high speed 80000 CPH LED bulbs DOB making pick and place machine
Product Features Description
1. double module, total 20 heads, each part 10 heads, can produce two types of products at the same time.
2. The X Axis is magnetic liner motor, Y axis and Z axis is servo motor, very good performance and high accuracy.
3. It's intelligent, can produce different types of LED light and electric board, such as LED bulb, flexible strip, Panel light, Down light, street light,power driver, other electronic boards, etc.
4. Its high precision and accuracy, apply to LED chips, resistor, capacitor, IC, shaped components etc.
Machine main parameter
| Length |
1200mm |
| Width |
1930mm |
| Height |
1500mm |
| Total weight |
2500kg |
| PCB Length width |
Double side, double track:
Max: 450*300mm Min: 80*80mm
|
|
Single side, single track:
Max: 450*540mm Min: 80*80mm
|
| PCB Thickness |
0.1-6mm ( If <0.6mm need jig) |
| No. Of feeders station |
64PCS |
| No. Of head |
20PCS |
| Operating environment |
23℃±3℃ |
| Power consumption |
6KW |
| X, Y, Z Axis drive way |
High-end magnetic linear motor and serve motor |
| Feeding way |
Electric feeder with double motor |
Company Introduction
mature experience: From 2007 to now, ETON has 15 years of R & D experience, professional and reliable.
Powerful products:ETON has universal machine and high-speed machine to meet all kinds of needs of different customers.
Proprietary technology: Since its establishment, ETON has been constantly studying and forging ahead. So far, it has obtained 133 certificates, including 9 invention patents, 12 software copyrights and 112 practical patents
Certificate of honor: ETON has won many awards with high gold content, such as the 2015 national high tech enterprise award, the industry special contribution award, the 4th China led initiative award and so on.
China domestic:ETON has an absolute market share in China, more than 80% of LED lamp manufacturers are our customers.
Abroad:ETON'S chip mounters are exported to more than 20 countries such as South Korea, India, Vietnam, Tunisia, Egypt and Turkey. There are many honorary customers, such as TCL, POLYCRB, Surya, CALCOM, etc.
Professional solution:We can customize a whole SMT production line for customers.
Free-installation:on-site free installation to ensure production smooth.
Free technical training:Free debugging and free staff training for customers.
Free technical support:7*24 technical online support.
Free software upgrade:Provide lifelong free software upgrade service.
One year warranty:If customers buy our machine, they will get a one-year overall warranty service.
Package and Transport
FAQ
1.How about your company?
We have more than 11 years experience and have obtained a number of intellectual property technologies.Our products are exported to more than 20 countries and regions.
2.What’s the terms of payment?
T/T is OK. You can choose FOB Shenzhen.
3.Why choose us?
ETON is the famous brand for high-end pick and place machine. We have more than 10 years experience and professional R&D team, providing 24 hours quick response after-sales service.
4.How long is the period for delivery?
30 days after deposit.
5.What are the main types of pick and place machine in your company?
The pick and place machine from ETON have two types, multifunctional pick and place machine and high-speed pick and place machine. The highest speed will reach 250000 CPH and produce 4 different types of material at the same time. In 2022, the newest machine has been born——ETON HONOR SERIES. Our machine can satisfy the different needs of your production.
