Product Details:
Payment & Shipping Terms:
|
| Name: | Pick And Place Machine | Dimension: | 1650*2000*1550 Mm |
|---|---|---|---|
| Power: | 380 AC 50 HZ | Total Weight: | 2800kg |
| Software: | R&D Independently | System: | Windows7 |
| Power Consumption: | 8KW | Warranty: | 1 Year |
| Visual Camera: | 4 Sets Of Imported Camera | PCB Length Width: | Max 500*300mm Min 100*100mm |
| High Light: | Automatic LED Mounter Machine,Bulbs LED Mounter Machine,80000CPH automatic led lights assembly machine |
||
Details of smt assembly machine
1. 2 sets of imported cameras, synchronously recognize, effectively ensure mounting speed and precision.vision for the flight identification,mark correction.
2. Dual system,dual module multifunctional mounter.to produce two different products at same time.
3. XY drive uses imported high-precision grinding ball screw rod + imported heavy-duty linear guide, quick positioning, low noise, high precision.
4. Servo Motor and Drive and precise linear guide,high-precise nozzles, automatic feeding integrated system , strong stability, promise 24-hour mounting stably.
Technical parameter of smt assembly machine
| HT-E5D | ||
| PCB | PCB length width | Max:500*300mm min:100*100mm |
| PCB thickness | 0.5~3mm | |
| PCB clamping | Electric clamping + Adjustable pressure pneumatic | |
| Mounting mode |
Group to picking and separate to placing Separate to picking and separate to placing |
|
| O.S. | system | Windows 7 |
| software | R&D independently | |
| display | Touch screen monitor | |
| Input device | Keyboard , mouse | |
|
Vision system |
No.of camera |
2sets of imported camera Vision for the alignment identification,mark correction |
| Mounting precision | 0.02mm(repeat precision) | |
| Mounting height | <36mm | |
| Mounting speed | 80000CPH | |
| Components space | 0.2mm | |
| Power | 380AC 50HZ | |
| Power consumption | 8KW | |
| Conveyor transmission | Max length:500mm | |
| Transmission speed | >500mm/sec | |
| Transmission direction | Both direction | |
| Transmission mode | Auto online drive | |
| Air pressure | >5.0kg /cm² | |
| Electrical control | Independent research and development by ETON | |
| X,Y,X axis drive way | High-end magnetic linear machine + Servo motor control for X,Y,Z axis | |
| Feeding way | ||
| Feeding system | No.of feeders station | Duel mode.totally 60 |
| No.of nozzles | Dual mode.totally 16 | |
| Feeding way | Electric feeder with double motor | |
Pick and palce machine HT-E5D
Application of smt assembly machine
Attention
1. Before using the Pick and Place machine, you must understand the basic parameters of the placement machine;
2. Before running the Pick and Place machine, the operator should do a comprehensive inspection of the machine.
3. According to the boot operation sequence to implement the Pick and Place machine, there must have a detailed machine operation instructions;
4. It is necessary to conduct regular troubleshooting and maintenance work on the Pick and Place machine in a timely manner.
