Name: | Pick And Place Machine | Warranty: | 1 Year |
---|---|---|---|
Length: | 2550mm | Width: | 1650mm |
Height: | 1550mm | Total Weight: | 1700kg |
High Light: | DOB Bulb Pick And Place Equipment,Multifunctional Bulb SMT Mounter Machine,PCB driver SMT Mounter Machine |
SMT pick and place machine with multifunctional appliance like DOB bulb and PCB driver
Product Description
HT-E8S-1200 is a multi-functional single-module high-end maglev SMT pick and place machine.
Multi-function means powerful functions, and can produce a variety of products, such as various LED lights, DOB bulbs, LED light tubes, LED light strips, display screens, lenses, flood lights, etc. Of course, it can also be perfectly mounted on various home appliances Using the driver board, the electronic components that can be mounted include IC, resistors, capacitors, etc.
A single module refers to a set of systems and a placement head, with a total of 12 nozzles and 28 feeder bases, which can convey a variety of materials. Under ideal conditions, the optimal production capacity is 45000CPH, and the speed advantage is obvious among products of the same level.
Linear motor refers to a motor with higher precision, longer service life and more stable product, and the most overall function has a significant addition.
Exclusive patent
Electronic feeder feeding system.
Vision alignment flight identifications, Mark correction.
Non-stop material re-loading function
Auto-optimization after coordinates generated, etc.
Parameter
No. of Camera | 2 sets of imported camera |
Vision for the flight identification, MARK correction | |
Mounting Precision | ±0.04mm |
Mounting Height | <15mm (Automatic Changing) |
Mounting Speed | 45000 CPH |
Components | LED , capacitors, resistors, IC,shaped components, etc. |
Components Space | 0.2mm |
No. of Feeders Station | 28 PCS |
No. of nozzles | 12 PCS |
Power | 380AC 50HZ |
Power Consumption | 4 KW |
Operating Environment | 23℃±3℃ |
Conveyor transmission | Max length :1200 mm |
Transmission Speed | >1000mm/sec |
Transmission Direction | Both direction (option) |
Transmission Mode | Auto online drive |
Air supply | 0.4-0.6mpa (4-6kgf/cm2)150N/min |
Electrical control | Independent research and development by ETON |
X,Y,Z Axis Drive way | High-end magnetic linear motor + Servo motor |
Feeding way | Electric feeder with double motor |
