SMT chip pick and place machine for rolling strip,flexible led strip

SMT chip pick and place machine for rolling strip,flexible led strip

Parameter

Dimension:3454*3035*1777mm

Total Weight:3100 kg

PCB Length Width:250*any length

PCB Thickness:0.1-0.5mm

PCB Clamping:Vacuum adsorption, cylinder splint, adjustable track width

Mounting Mode:Group picking and group placing

Mounting speed: 500000 CPH(optimum speed)

Repeat mounting Precision:±0.05mm (Repeat precision)

Mounting Height:≦5mm

Components:LED 3014/ 3020/ 2835/ 5050 and capacitors, resistors, bridge rectifiers, etc.

No. of Feeders Station:136pcs

No. of head:136pcs

Power:380AC 50 HZ

Power Consumption:9.6kw

What is SMT?

SMT is surface mounting technology, it is a process of soldering components on the PCB after mounting. So it needs stencil printer, pick and place machine, reflow oven. The solder paste is missed on the PCB by stencil printer

The pick and place machine will pick the components and then mount on the PCB.After that, reflow soldering will solder them together in order to stick more firmly.

Our pick and place machine turns the bare PCB of the first picture into the PCBA of the second picture by mounting small components You can clearly see that compared with the two pictures, there are many more parts in the second picture.

Production line

Significance

1,electronic products pursue miniaturization, previously used perforated plug-in components have been unable to shrink

2,electronic products more complete function, the use of integrated circuits (IC) has no perforated components, in particular, large-scale, high-integration IC, have to use surface mount components.

3,Mass production, automation, low-cost, high-volume, high-quality products to meet customer needs and enhance market competitiveness.

4,the development of electronic component, the development of integrated circuits (IC) .

5,the List of semiconductor materials technology revolution is imperative
