| Name: | Semi-auto Solder Paste Screen Printer,SMT Stencil Printer,Long Board SMD Printer,PCB Screen Printing Machine,semi Automatic Stencil Printer | Dimensions: | 900*900*1650mm |
|---|---|---|---|
| Platform size: | 470-750 Mm | Weight: | 150kg |
| Precision: | ±0.02mm | Power Consumption: | 100 W |
| Warranty: | 1 Year | Application: | SMT PCB Assembly Production Line,Electronic Components,printing The Solder Cream Onto The PCB,SMT PCB Screen Printing Machine |
| Applicable Components: | 0402,0402~5050 | ||
| High Light: | Semi Auto SMD Stencil Printer,100w SMD Stencil Printer,Single phase smt stencil machine |
||
smd solder paste printing control pcb screen printing automatic screen printing machine solder paste screen printer solder paste stencil machine smt printer
Details of SMT Stencil Printer
The printing base can be lifted up by 45° and can be fixed, which is convenient for the loading and unloading of the scraper and the cleaning of the stencil.
The Printing Block can be moved forward and fixed, which is convenient to match the position of the stencil mesh pattern to obtain better printing results.
The mesh support arm can be adjusted left and right separately, suitable for 550～650mm stencil.
The combined printing platen is equipped with a fixed slot and a positioning PIN, which is quick to change and easy to locate, and is suitable for single-sided substrate and double-sided substrate operations.
The correction method adopts the movement of the net support arm to coordinate the X, Y, Z correction adjustment of the printed matter (platen), and the correction is convenient and simple.
Specifications of SMT Stencil Printer:
| Model | ET-S400X |
| Dimensions | L670*W850*H1650mm |
| Platform size | 320*500mm |
| PCB size | 400*300mm Min:0.4~2.0mm |
| Stencil Frame Max.size | 370*470mm 420*520mm 550*650mm |
| Printing speed | 0-9000mm/min ;Adjustable |
| Fixed printing position | Positioning pin |
| XY direction adjustment of the table | Adjustable from front to back to left and right ±10mm |
| Printing accuracy | ±0.05mm |
| Repeatability | ±0.02mm |
| Minimum component spacing | 0.3mm |
| Air pressure | 4-6kgf/cm2 |
| Power | Single phase 220V, 50/60Hz, 100W |
| Weight | 250kg |
SMT stencil printer
application of SMT stencil printer
Automatic stencil printer machine with pick and place machine, loader, conveyor, unloader, reflow oven to be one automatic line. Automatic line save much labor cost compared with the semiautomatic line, also with higher printing precision could produce high quality electrical products. Here are the automatic SMT line solution layout:
