Product Details:
Payment & Shipping Terms:
|
| Weight: | 700KG | Voltage: | 220V 50/60Hz 100W |
|---|---|---|---|
| Condition: | New | Plate Type: | Screen Printer |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Automatic Grade: | Automatic |
| Dimensions(l*w*h): | 1240(L)X1450(W)X1650(H)mm | Warranty: | 1 Year |
Features
The PCB loading direction can be selected and combined freely.
Adopt High-speed multi modular head,apply to ultra small chip 0201~40*40mm large Chip,wider component range.
Unique crafted internal gear conveyor belt to prevent jamming.
X, Y axis adopts high-precision grinding ball screw, driven by servo motors at both side.
The optimally designed module drive structure effectively improves the stability of the platform calibration, and realizes ultra-small transmission under fine-tuning, so that the machine can meet the printing requirements of higher precision.The structure is simple and reliable, the adjustment is convenient, and the height adjustment of the support PIN of the PCB board with different thicknesses can be quickly realized.
Cast aluminum scraper beam to ensure smoother running of scraper
Programmable Suspension Self-Adjusting Stepper Motor Drives Print Head.
Easy-to-learn and easy-to-use friendly operation interface.
Technical parameter
| Model | ET5235 |
| Screen Frames max size | 737mm |
| Screen Frames min size | 470mm |
| Screen Frames thickness | 25~40mm |
| PCB size(L* W) |
Max size:520mm*350mm Min size:50mm*50mm |
| PCB Thickness | 0.6-6mm |
| Transport height | 900±20mm |
| Transport speed | Max 1200mm/s Programmable |
| Stencil separation speed | 0.1~20mm/sec Programmable |
| Printing accuracy | ±0.025mm |
| Cycle time | ≤9s (Exclude printing & cleaning) |
| Product changeover | <5Min |
| Air required | 2 |
| Control method | AC:220±10%,50/60HZ 1Φ3KW |
| Weight | 1240(L)×1450(W)×1650(H)mm |
| PCB transfer overhead height | 10mm |
