| Warranty: | 1 Year | Name: | SMT Pick And Place Machine |
|---|---|---|---|
| Power Supply: | 380AC 50HZ | Condition: | New |
| Weight: | 1700kg | Dimension: | 2700*2300*1550mm |
| Feeders: | 34 | Pcb Thickness: | 0.5~5mm |
Product Features
Product application
Apply to the 0.6M,0.9M,1.2M rigid PCB and 0.5M,1M LED flexible strip . Producing with 2~4 types of materials with high capacity , available for board with any proportion of LED chip and resistor .
Technical parameter
| Model | F7S |
| Length | 2700mm |
| Width | 2300mm |
| Height | 1550mm |
| Total Weight | 1700kg |
| PCB size(L* W) | 1200*330mm Min；100*100mm |
| PCB Thickness | 0.5-5mm |
| PCB Clamping | Adjustable pressure pneumatic |
| Mounting mode | Group to take and group to mount |
| System | Windows 7 |
| Software | R&D Independently |
| Display | Touch screen monitor |
| Input Device | Keyboard, mouse |
| No.of camera | 5 sets Digital camera(Digital camera) |
| Components | LED3014/3020/3528/5050,capacitors,resistors,bridge rectifiers etc |
| No.of feeders station | 68PCS |
| No.of nozzles | 34PCS |
| Power | 380AC 50HZ |
| Operating environment | 23℃±3℃ |
| Conveyor transmission | Max Length:1200mm |
| Transmission speed | >500mm/sec |
| Transmission direction | Single |
| Transmission mode | Online drive |
| Position mode | Optical |
| Air supply | 0.4-0.6mpa(4-6kgf/cm )150N/min |
| Electrical control | Independent research and development by ETON |
| X,Y,Z Axis drive way | High-end magnetic linear motor +Servo motor |
| Feeding way | Electric feeder with double motor |
After service
Engineers can arrive on site to teach operation and debug the machine
24 hours to deal with problems online, arrange engineers to solve problems
Software lifetime upgrade
Regular visit (one year warranty period, spare parts repair free; Once or twice a year after warranty)
SMT placement machine failure analysis ideas
1 Detailed analysis of the working order of the smt placement machine and the logical relationship between them.
2. Understand the location, link and extent of the fault, and whether there is any abnormal sound.
3 Understand the operation process before the failure occurs.
4 Whether it occurs on a specific placement head and nozzle.
5 occurs on a specific device.
6 whether it happens on a specific batch.
7 Whether it happened at a particular moment.
