Brand: | ETON | Model: | HT-T9 |
---|---|---|---|
Length: | 3100mm | Width: | 2300mm |
Height: | 1550mm | Total Weight: | 1700kg |
Neon soft strip mounting making machine 2835 5050 chip mounting modol
LED soft light belt production machine
many of our machines can produce soft light belts, such as T9, T9 can produce soft light belts of any length of 50 meters, 100 meters, and 200 meters. T9 has 68 Feida and 68 suction nozzles, with a capacity of 250K. At the same time, it produces four different materials without affecting the high production capacity. There are four modules of double film heads and 17 suction nozzles in each group. It has a correction function and can be mounted with RGB.
Equipment required for making soft light strip
PCB Loader--Semi-automatic stencil printer--1.6m Buffer stage--pick and place machine--T9--3m Belf line--6m Belt line--6m Belt line--6m Belt line--3m Belt line--Reflow oven--PCB Unloader
Technical parameter
Model | HT-T9 |
Dimension | |
Length | 3100mm |
Width | 2300mm |
Height | 1550mm |
Total Weight | 1700kg |
PCB | |
PCB Length Width | 250mm*any length |
PCB Thickness | 0.5-1.5mm |
PCB Clamping | Vacuum adsorption, cylinder splint, adjustable track width |
Mounting Mode | Group picking and separately placing |
O.S. | |
System | Windows7 |
Software | R&D independently |
Display | Touch screen monitor |
Input Device | Keyboard, Mouse |
Vision System | |
No. of Camera | 5 PCS ( Digital camera) |
Vision alignment, MARK correction | |
Repeat mounting Precision | ±0.02mm (Repeat precision) |
Mounting Height | ≦5mm |
Mounting Speed | 200000~250000CPH |
Components | LED 3014/ 3020/ 3528/ 5050 and capacitors, resistors, bridge rectifiers, etc. |
Components Space | 0.5mm |
No. of Feeders Station | 68 PCS |
No. of head | 68 PCS |
Power | 380AC 50 HZ |
Power Consumption | 6kw |
Operating Environment | 23℃±3℃ |
Conveyor transmission | Max Length :1000 mm |
Transmission speed | >500mm/sec |
Transmission Direction | Single(left→ right or right→ left) |
Transmission Mode | Online drive |
Positioning Way | Optical |
Gas consumption | 0.4-0.6mpa (4-6kgf/cm2)150N/min |
Electrical control | Independent research and development by ETON |
Motion control card module 1 set | Independent research and development by ETON |
X,Y,Z Axis Drive way | High-end magnetic linear motor+ servo motor |
Feeding way | Electric feeder with double motor |
Packing
Our mode of transportation including water, land and air transportation.You can choose the most suitable way according to your requirements.
Our packing is made of wooden box with vacuum package, and we promise to deliver the goods within four weeks after payment.
FAQ
Q: How is the training?
A: After purchasing our products, you can send your engineers to study in our factory, or we can send our engineers to yourfactory to train your staff for you .
Q: Do you have a product certification certificate?
A: Our products have CCC, CE, SRIA certification.
Q: How about the after-sale service? How about the warranty?
A: We have a team of professional engineers to solve your problems. Any parts that require repair and replacement are free ofcharge during the warranty period. We can also provide you with training and on-site installation, and support remote control of the machine, the machine uses Chinese and English interface, very easy to operate.
