| Name: | Pick And Place Machine | No. Of Feeder Station: | 136PCS |
|---|---|---|---|
| No. Of Heads: | 136PCS | No. Of Camera: | 10 PCS |
| Model: | HT-T9-2S | Mounting Mode: | Group Picking And Group Placing |
| PCB Size: | 250（±10）mm*Any Length | ||
| High Light: | 10 Camera SMT Mounter machine,Four Module SMT Mounter Machine,100m Led strip light making machine |
||
Four module smt mounter for 5m to 100m led long strip with 10 camera and 500000 CPH Capacity
Machine tachnical parameter
| Model | T9-2S |
| PCB length width | 250(±10)mm*Any length |
| PCB thickness | 0.1-0.5mm |
| PCB clamping | Vacuum adsorption, cylinder clamping, track width adjustable |
| Mounting mode | Group picking and group placing |
| System | Windows 7 |
| Software | R&D independently |
| Display | LED display |
| MES system | Customized(Option) |
| No.of camera | 10 sets Vision alignment+Mark correction |
| Mounting precision | ±0.05mm/±0.05mm(Repeat precision) |
| Mounting height | ≤5mm |
| Mounting speed (Optimum) | Double side 500000CPH,Single side 250000CPH |
| Components range | LED3014/3020/2858/505 and resistor,capacitors,bridge rectifiers |
| Components space | 0.5mm |
| Power | 380AC 50HZ |
| Power consumption | 9.6KW |
| Operating environment | 23℃±3℃ |
| Conveyor transmission | MAX Length:1000mm |
| Transmission speed | ＞500mm/sec |
| Transmission direction | Singles(left→right or right→left) |
| Transmission mode | Online drive |
| Position mode | Optical |
| Gas consumption | 0.4-0.6mpa(4-6kgf/cm²)150N/min |
| Electrical control | Independent research and development by ETON |
| Motion control card module 1 set | Independent research and development by ETON |
| X,Y,Z Axis drive way | High-end magnetic linear motor +Servo motor |
| Feeding System | |
| No. of Feeders station | 136PCS(single station 68PCS) |
| No.of Nozzles | 136PCS(Single side 68PCS) |
| Feeding way | Electric feeder adopts single motor |
The applications
Company advantages
1. SMT equipment: Pick and place machine/reflow oven/stencil printer/pcb conveyor/SPI/AOI.etc
2. Light Factory for :led bulbs,DOB,lens,panel light,downlight,streetlight,tube,0.5m,1m strip light,etc.
3. Provide Overseas engineers for Free installation and free training.
4. TOP brand of China SMT machine manufacturer,500 employees for ETON
5. Oversea market:The products exported to more than 30 countries and regions, including South Korea, India, Vietnam, Tunisia, Egypt,Turkey, Russia, Brazil etc.
We can provide SMT line solution and better serivce for you!
