| Name: | Stencil Printer | Brand: | ETON |
|---|---|---|---|
| Model: | ET-5235 | Dimension: | 1240*1450*1650MM |
| Weight: | Approx: 700KG | Product Changeover: | <5min |
| High Light: | Automatic Solder Paste Printing Machine,LED Lights SMT Solder Paste Printer,Street Lights SMT Solder Paste Printer |
||
SMT assembly machine automatic printing machine for LED flood and street lights
The parameter
| model | ET-5235 | |
| Screen frames | Max size | 737mm |
| Min size | 470mm | |
| thickness | 25-40mm | |
| Dimension | 1240*1450*1650MM | |
| weight | Approx: 700KG | |
| PCB transfer overhead height | 10mm | |
| PCB size | Max: 520*350mm, min: 50*50mm | |
| PCB thickness | 0.6-6mm | |
| Transport height | 900±20mm | |
| Board location | Support system | Magnetic pin / up-down table adjusted by manual |
| Clamping system | Unique top flattened, side clamping | |
| Print head | Two independent direct connect motor driven print heads | |
| Squeegee type | Steel scraper(standard), PV scraper( option) | |
| Stencil separation speed | 0.1-20mm/sec programmable | |
| Cleaning system | Dry, wet, vacuum (programmable) | |
| Cycle time | ≦9s(exclude printing& cleaning) | |
| Product changeover | <5min | |
The features of ET-5235
1. The direction of PCB loading can be freely selected and combined
2. Adopt Arch bridge-shaped suspension hanging direct-connect scraper
3. Cast aluminum scraper beam, running of scraper is smoother
4. suspension self-adjusting stepper motor drives print head is Programmable.
5. The fully closed-loop scraper pressure feedback device monitor the scraper pressure at all times, making the printing more full.
6. scale is Embedded and never fall off.
SMT production line
The whole SMT production line machine mainly include stencil printer, pick and place machine, conveyor and reflow oven.
Stencil printer:Put the solder paste on the PCB board
Conveyor: transmission the PCB board to pick and place machine
Pick and place machine:mounting the components on the PCB board
reflow oven:heating the PCB board
