High capacity 180K smt chip mounter tube/strip making pick and place machine
LED module mounter machine introduction
LED module mounter machine also called pick and place machine/ placement machine/SMT machine. It is one of SMT Line. The function of mounter is picking components and then mounting on the PCB. It is automatically SMT Machine.
In SMT production line, there are different machines for different module with different functions. Included Loader, Conveyor, Stencil printer, pick and place, reflow oven, un-loader, etc.
F7S Mounter main technology parameters
1. Module: HT-F7S
2. Machine functions: Picking components and then mounting on the PCB
3. Mounting mode: Group picking and group mounting, feeding missing components automatically
4. PCB Clamping: Adjustable pressure pneumatic
5. System: Windows 7
6. Display: Touch screen monitor
7. No. of camera : 5 pcs digital camera, vision alignment, mark correction
8. Mounting speed: 180000 chip per hour
9. Power consumption: 5 kw
10. X,Y, Z Axis Drive way: High-end magnetic linear motor+ servo motor
Parameter
|
Model
|
HT-F7S
|
|
PCB Length Width
|
Max:1200*330mm Min:100*100mm
|
|
PCB Clamping
|
Adjustable pressure pneumatic
|
|
O.S.
|
|
System
|
Windows7
|
|
Software
|
R&D independently
|
|
Vision System
|
|
Mounting Speed
|
180000 CPH
|
|
Components
|
LED 3014/ 3020/ 3528/ 5050 and capacitors, resistors, bridge rectifiers, etc.
|
|
Power
|
380AC 50 HZ
|
|
X,Y,Z Axis Drive way
|
High-end magnetic linear motor+ Servo motor
|
|
Feeding System
|
|
No. of Feeders Station
|
68 PCS
|
|
No. of head
|
34 PCS
|
|
Feeding way
|
Electric feeder with double motor
|
Application of F7S Mounter
F7S is the super high speed pick and place machine, it is suitable for mounting board within 1.2 meters. Widely apply to rigid PCB and flexible PCB. And suitable for mounting led chip, resistor, bridge, RGB, etc.
So F7S very suitable for led module lighting, such as LED TUBE, Strip, panel, street light, display, etc.
