Warranty: | 1 Year | Name: | SMT Pick And Place Machine |
---|---|---|---|
Power Supply: | 380AC 50HZ | Condition: | New |
Weight: | 1700kg | Mounting Speed: | 250000CPH |
Dimension: | 3100*2300*1550mm | Feeders: | 68 |
Pcb Thickness: | 0.5~1.5mm | Positioning Accuracy: | 0.02mm |
High Light: | 68Heads LED Pick And Place Machine,Highspeed SMT Chip Mounter CCC,two arms SMT Chip Mounter |
Product description
1,The SMT high speed mounter HT-T9 is designed with 68 suction nozzles and 68 feeding stations. It is controlled by two arms, with 34 suction nozzles controlled by one arm each. Among them, 34 suction nozzles are divided into two groups, each with 17 nozzles, and each group is jointly controlled by a servo motor and a corner motor.
2,The four different materials of a product can be pasted simultaneously, which can accelerate product production without affecting high productivity.
3,The mounter HT-T9 is suitable for one-time mounting of soft light strips with a length of 5 meters, 20 meters, 50 meters, or even more.
4,During mounting, a single plate of material can be attached separately, and the same plate of material is always attached to the same light bar.
5,Calibration automatically,high precision,available for RGB.
6,Exclusive patent technology:group to take and group to mount.
Equipment Details
The stator itself is a permanent magnet, and the interaction between the moving stator and the magnetic pole causes repeated movement of the mounting head.
Transport the PCB board to the designated location,the platform has an adsorption function, which is conducive to adsorption of soft PCB boards.
Detect if there is a PCB on the track.
Parameter
Product name | SMT high speed mounter |
Model | HT-T9 |
PCB size(mm) | Max:250*any length |
Mounting precision | ±0.05mm |
Mounting height | ≤5mm |
Mounting speed | 200000-250000CPH |
Components | LED3010/3020/5050/3525 resistors, capacitor, etc. |
Components space | 0.5mm |
No.of feeders station | 68 PCS |
No.of heads | 68 PCS |
Positioning way | Optical |
Feeding way | Electric feeder with double motor |
X,Y Axis drive way | High-end magnetic linear motor and servo motor |
Package
We usually use vacuum wooden boxes to package our products. Vacuum can be very shockproof and ensure the integrity of the product. If you have special requirements for packaging, we can also achieve them for you.
Our Service
Global Service Office: India·Turkey·Vietnam·Egypt·Pakistan
Professional solutions: Provide professional SMT Full line solutions
Free Warranty: One-year warranty factory service. All parts damaged within the warranty period shall be replaced free of charge
Free Installation: On-site free installation to ensure smooth production.
Free Technical Training: Professional training of operating and maintenance.
Free Technical Support: 7 * 24 technical online support.
Free Software Upgrade: Offer free software upgrade whole lifetime
FAQ
Q1: What are the trade terms commonly used by your company?
A: We usually use EXW and FOB.
Q2: What valuable services can I obtain after purchasing a SMT high speed mounter?
A: We will follow up all processes, help you clear customs, and do our best to ensure your interests. At the same time, after your production is on track, we will also visit regularly to share your latest industry information.
