| Warranty: | 1 Year | Applicable Components: | 0402 |
|---|---|---|---|
| Name: | SMD Chip Mounter,SMT Pick And Place Machine,SMT Chip Mounter | Application: | SMT Mounting Shooter Machine,SMT Production Line |
| Condition: | 100% Original,Brand-new | Mounting Speed: | 180000 CPH |
| Type: | Automatic | Usage: | SMT Mounting Machine,LED |
| Feeders: | 68pcs | ||
| High Light: | Rigid PCB SMT Mounter,LED Chips SMT Mounter,180K CPH LED Pick And Place Machine |
||
Rigid PCB board making mounter HT-F7S 180000CPH for LED chips pick and place machine
HT-F7S SMT Mounting Machine LED Strip
HT-F7S is applicable to 0.6m, 0.9m, 1.2m hard lamp board, 0.5m, 1m LED strip light and panel lamp. It can also produce RGB strip light.
2-4 kinds of materials can be pasted at the same time.
F7s is a high-speed machine that can mount different products. As we all know, in the process of increasing speed, many manufacturers will choose to sacrifice some functions, such as manufacturing a mounter dedicated to one product. The different feature of the f7s machine produced by Eton is that as a high-speed machine, it can also mount a variety of products.
In addition, it also attracts LED manufacturing factories. The patch accuracy reaches the repetition precision of ±0.02mm, which is a great advantage for high-standard LED products. This machine will certainly improve your quality.
Parameter
| Model | HT-F7S |
| Dimension | |
| Length | 2700mm |
| Width | 2300mm |
| Height | 1550mm |
| Total Weight | 1700kg |
| PCB | |
| PCB Length Width | Max:1200*330mm Min:100*100mm |
| PCB Thickness | 0.5-5mm |
| PCB Clamping | Adjustable pressure pneumatic |
| Mounting Mode | Group picking and Group placing |
| O.S. | |
| System | Windows7 |
| Software | R&D independently |
| Display | Touch screen monitor |
| Input Device | Keyboard, Mouse |
| Vision System | |
| No. of Camera | 5 sets ( Digital camera) |
| Vision alignment, MARK correction | |
| Repeat Mounting Precision | ±0.02mm(Repeat precision) |
| Mounting Height | ≦5mm |
| Mounting Speed | 150000~180000 CPH |
| Components | LED 3014/ 3020/ 3528/ 5050 and capacitors, resistors, bridge rectifiers, etc. |
| Components Space | 0.5mm |
| Power | 380AC 50 HZ |
| Power Consumption | 6kw |
| Operating Environment | 23℃±3℃ |
| Conveyor Transmission | Max Length :1200 mm |
| Transmission Speed | >500mm/sec |
| Transmission Direction | Single(left→ right or right→ left) |
| Transmission Mode | Online drive |
| Positioning way | Optical |
| Air supply | 0.4-0.6mpa (4-6kgf/cm²) 150N/min |
| Electrical control | Independent research and development by ETON |
| Motion control card module 1 set | Independent research and development by ETON |
| X,Y,Z Axis Drive way | High-end magnetic linear motor+ Servo motor |
| Feeding System | |
| No. of Feeders Station | 68 PCS |
| No. of head | 34 PCS |
| Feeding way | Electric feeder with double motor |
