| Application: | LED Strip | Power Supply: | 380AC 50HZ |
|---|---|---|---|
| Warranty: | 1 Year | Condition: | New |
| Weight: | 3100 Kg | Mounting Speed: | Double Side: 500,000 CPH Single Side: 250,000 CPH (Optimum Speed) |
| Dimension: | (L)3454*(W)3035*(H)1777 Mm | Pcb Thickness: | 0.1-0.5 Mm |
| High Light: | Roll Strip SMT Placement Machine,200m Strip SMT Placement Machine,Two Times Picking SMT Placement Machine |
||
Two times picking and once placing 200 roll strip placement machine
Description
Feature ① HIGH PRODUCTIVITY
Component picking position can be adjusted according to PCB pad pitch, min 6.5mm. Apply to LED 3014/3020/2835/5050 resistor, capacitor,bridge rectifier etc. wide component range.
Recognition camera record the component leaking position of PCB,and fill the missing component accordingly.
The placement head adopt the method of two times picking and once placing.The placement time greatly minimizedwith the improved placement way, excellent optimum capacity reach 500000CPH.
Feature ② FLEXIBLE PRODUCTION
1M per cycle.
realize the function of two time picking and once placing.The range of feeding station is double of placement head,can produce four kinds of materials at the same time.
| Model | T9-2S |
| Dimension | |
| Length | 3454mm |
| Width | 3035mm |
| Height | 1777mm |
| Total Weight | 3100kg |
| PCB | |
| PCB Length Width | 250 (±10mm)*Any Length |
| PCB Thickness | 0.1-0.5mm |
| PCB Clamping | Vacuum adsorption, cylinder clamping, track width adjustable |
| Mounting way | Group picking and group placing |
| Vision System | |
| No. of Camera | 10 sets (Digital camera) |
| Vision alignment+Mark correction | |
| Mounting Precision | ±0.05mm |
| Mounting Height | ≤5mm |
| Mounting Speed | Double side:500000CPH,single side:250000CPH(Optimum speed) |
| Components | LED3014/3020/2835/5050 and resistor,capacitors,bridge rectifiers etc. |
| Power | 380AC 50HZ |
| Power Consumption | 9.6 KW |
| Operating Environment | 23℃±3℃ |
| Conveyor transmission | Max length :1000 mm |
| Transmission Speed | ＞500mm/sec |
| Transmission Direction | Single ( left—>right or right—Heft) |
| Transmission Mode | Online drive |
| Position Mode | Optical |
| Air supply | 0.4-0.6mpa (4-6kgf/cm2)150N/min |
| Electrical control | Independent research and development by ETON |
| Motion control card module 2 set | Independent research and development by ETON |
| X,Y,Z Axis Drive way | High-end magnetic linear motor + Servo motor |
| Feeding System | |
| No. of Feeder station | Double side:136PCS(single side:68PCS) |
| No.of head | Double side:136PCS(single side:68PCS) |
| Feeding way | Intelligent electric feeder with double motor |
