| Name: | SMD Pick And Place Machine | Head: | 24 PCS Double Module |
|---|---|---|---|
| Feeder Station: | 48pcs Double Module | Applicable Components: | 0402,SOP,QFN,IC,0805 |
| Mounting Speed: | 90000CPH | Total Weight: | 2000kg |
| Warranty: | 1 Year | Power: | 380AC 50HZ |
| Power Consumption: | 8KW | Mounting Height: | <36mm |
| Condition: | 100% Original,Brand-new | Dimension: | 3150*2250*1650mm |
| High Light: | SMT LED Chip Mounter,dual system LED Chip Mounter,PCB Pick and Place Robot Machine |
||
Function of smd mounting machine
1. Platform drive adopts panasonic servo motor from Japan, and lead screw with linear guide rail to ensure the stability and control accuracy of platform movement.
2. The X and Y axis adopt high-end magnetic linear motors to ensure the high accuracy, speed and stability of the patch.
3. 16 high-speed heads work at the same time, greatly improving the cost performance of the equipment. Suction head movement, high precision, long durability.
4. Simple and easy to understand graphical programming, greatly improve the convenience of operation, automatic visual positioning to assist positioning, positioning accurate and convenient.
5, the use of industrial computer + independent special controller control, system stability, simple operation, easy to learn.
Technical parameter of SMD mounting machine
| Technical parameter | |
| PCB | |
| PCB length width | Max:1200*300mm min:100*100mm |
| PCB thickness | 0.5~5mm |
| PCB clamping | Adjustable pressure pneumatic |
| O.S. | |
| system | Windows7 |
| software | R&D independently |
| display | Touch screen monitor |
| input | Keyboard mouse |
| Feeding system | |
| No. of feeders station | Dual mode ,totally 40 |
| No.of nozzles | Dual mode,totally 16 |
| Feeding way | Electric feeder with double motor |
Pictures of SMT machine
SMT line solution
In SMT Line, there are automatic stencil printer machine, pick and place machine, reflow oven machine, loader and un-loader machine. Different SMT line design will be little different. Some factory will using one automatic stencil printer machine for different SMT line. ETON will provide the professional suggestion for the line design.
FAQ
1. Do you supply PCB conveyor machine?
A: Yes, we supply whole SMT line machine, like the conveyor, pick and place machine, reflow oven machine, etc.
2. Is this automatic stencil printer machine suitable for printing lighting driver board?
A: Yes, this automatic stencil printer machine is very high precision, suitable for max pcb size is 400*340mm, printing accuracy reach 0.025mm.
3. What is this machine warranty ? And how about the after sales service?
A: We provide one year warranty, during warranty, any parts need to be repaired and replaced will be free. And we will support machine install and training online, also machine support remote control, machine will be very easy for operate.
