High efficiency Full-automatic 250000 CPH pick and place machine for Led tube/strip /panel lamp
The function of highspeed led mounting machine
The function of led chip mounter machine is mounting the components(led chip/ resistor/ capacitor/ ic/ shaped components etc) on the PCB. The led chip mounter machine is the main equipment in the SMT line, and also it influence whole SMT line capacity.
Machine parameter
| Model |
HT-F9 |
| Dimension(L*W*H) |
2700*2300*1550mm |
| Weight |
1700kg |
| PCB length width |
Max:1200*330mm;Min:100*100mm |
| PCB thickness |
0.5~5mm |
| Mounting precision |
±0.02mm |
| Mounting mode |
Group to take and group to mount |
| Mounting height |
≤5mm |
| Mounting speed |
250000 CPH |
| Power consumption |
6KW |
| No. Of feeders station |
68 PCS |
| No. Of head |
68 PCS |
SMT production line
ETON over 10 years experience in SMT machines, so we are very professional to provide whole line solution.
Automatic stencil printer machine with pick and place machine, loader, conveyor, unloader, reflow oven to be one automatic line.
Automatic line save much labor cost compared with the semiautomatic line, also with higher printing precision could produce high quality electrical products. Here are the automatic SMT line solution layout:
Company information
In 2007, Established Taipei R&D Center and began to develop placement machines
In 2015-2017, HT-T7(high speed pick and palce machine)/HT-E9(multi-function machine)was completed R&D and begin selling.
After 2018, HT-E5S/E5D,HT-E8S/E8D(new magnetic linear motor multifunctional placement machine was completed R&D and begin selling.
ETON has invented the fastest automatic pick and place machine with speed 250000CPH. We got large market share in USA, KOREA,INDIA, GERMANY,TURKEY more than 20 countries.We expanded our plant and built a new bigger industrial park in Jiangxi Province.
ETON have modern self-owned industrial park with 52,000 square meters. More than 500 employees , We have strong manufacturing capabilities.The annual sales scaled over 800 million yuan.
ETON smt machines for led production line. all kinds of pick and place machine, conveyor, uploader, stencil printer, relow oven and so on.
INDUSTRIAL PARK
We have our own industrial park,equipped with and advanced processing and manufacturing center,strict quality control,and standardize production,streamline production processes.and there is the fastest machine in the world,the capacity reach 50W CPH.
Shipping and Delivery
Land transportation: suitable for inland countries and it is affordable;
Air freight: for urgent good, and it is the most expensive transportation way;
Shipping: It’s suitable for heavy goods, and the convenience and lower cost of shipping which is easy for clients to accept the arrival time of the goods.
Related machine
We can provide you a whole SMT line solution and equipment, you can look this picture, we have semi-auto/full-automatic stencil printer, glue dispenser(this machine is mainly for making led lens), conveyor, reflow oven, etc.
We can meet your any demands for equipment, and pursue quality higher than price for machine manufacturing
Certificates
ETON s not only in the leading position in the field of photoelectric high speed placement machines, but also has made breakthrough progress in the field of smt high speed placement machine, it has successfully developed a variety of cost effective smt high speed universal placement machines.
ETON has obtained a number of intellectual property technologies,total 133 patents, including 9 invention patents, 112 practical patents, 12 software copyrights, also earned the oversea certificates as CE, CCC, SIRA,etc.
Service
Smt production line configuration (three core production equipment)
The general smt production process includes three steps of solder paste printing, pick and place machine and reflow soldering. The placement machine is the primary core equipment: it is used to achieve high-speed, high-precision, fully automatic placement of components, which is related to the efficiency and accuracy of the SMT production line, and is the most critical and complex equipment. In many equipment, the placement machine often accounts for more than 70% of the investment of the entire production line, so the selection of the placement machine is very important.
FAQ
Q1: What is your machine actual speed?
A1: The actual speed is influenced by many factors, such as the number of the components, the kind of products, the time of send board, etc.
Q2: do you only provide smt pick and place machine?
A2: no, we can provide whole line solution if you want, loader&unloader, conveyor, reflow oven etc.
Q3: how about the machines quality?
A3: We have our own industrial park. There are production centre and R&D centre and quality inspection centre to guarantee the machine quality.
