High efficiency Full-automatic 250000 CPH pick and place machine for Led tube/strip /panel lamp
The advantages of HT-F9 led tube light making machine
1. HT-F9, which has 68 heads, two mounting module, each mounting module has 34 heads;
2. HT-F9, which has 68 PCS of feeder station, adopt electric feeder with double motor feeding way
3. HT-F9, which Adopts group picking and group placing mounting mode, achieve high mounting speed;
4. HT-F9, which has uesd the high-end magnetic linear motor and servo motor, stepper motor to ensure the mounting speed and mounting precision
5. HT-F9, which has produced 4 types materials at the same time, for the Optimum mounting speed, it can reach 250000 CPH.
Machine parameter
| Model |
HT-F9 |
| Dimension(L*W*H) |
2700*2300*1550mm |
| Weight |
1700kg |
| PCB length width |
Max:1200*330mm;Min:100*100mm |
| PCB thickness |
0.5~5mm |
| Mounting precision |
±0.02mm |
| Mounting mode |
Group to take and group to mount |
| Mounting height |
≤5mm |
| Mounting speed |
250000 CPH |
| Power consumption |
6KW |
| No. Of feeders station |
68 PCS |
| No. Of head |
68 PCS |
SMT production line
For production line:including semi-automatic stencil printer, pick and place machine, conveyor and reflow oven.
the total length of HT-F9 pick and place machine is about 12.1 meter.
