High-Speed SMT Pick and Place Machine | 20 Spindles, Dual Gantry, Modular & IC Tray Compatible
Description
● Dual gantry, 20 spindles.
● Maximum PCB board: 500*300mm, minimum 50*50mm.
● Optional IC tray, ANC, flexible production
● Flexible wiring is achievable through modular placement
Heads and various production modes.
Machine main parameter
|
Model
|
YT20S-I
|
|
Dimension
|
1590mm*2680mm*1650mm
|
|
Total Weight
|
2200kg
|
|
PCB Length Width
|
Max:500*300mm Min:50*50mm
|
|
PCB Thickness
|
0.5-5mm
|
|
PCB Clamping
|
Cylinder clamping, track width adjustable
|
|
Mounting Mode
|
Group picking and separate placingseparate picking and separate placing
|
|
System
|
Windows10
|
|
Software
|
R&D independently
|
|
Display
|
LED monitor
|
|
Input Device
|
Keyboard, Mouse
|
|
No. of Camera
|
1 PCS (Head flight vision camera)
|
|
2 PCS Mark camera
|
|
Repeat Precision
|
CHIP±0.03mm IC/BGA±0.025mm Cpk ≧1.33 (3o)
|
|
Mounting Height
|
≦16mm (Other height can be customized)
|
|
Mounting Speed
|
98000 CPH(Under best condition)
|
|
Components
|
0201~15*15MM packaging material and IC material(Optional fixed camera for 0201~40*40MM),Other component size can be customized
|
|
Power
|
220AC 50HZ
|
Machine application
Our Exhibitions
As an experienced company of trading SMT pick and place machine with more than 30 countries and regions aboard, Eton has participated in many exhibitions of foreign countries, such as India Mumbai Exhibition, India Delhi Exhibition, Egypt Exhibition, Turkey Exhibition, Pakistan Exhibition, etc. And also we have took part in our domestic exhibition, like Guangzhou Guangya Exhibition, Shanghai Munich Exhibition, Chongqing LED light Exhibition, etc.
Related machine
ETON is a leading SMT high speed pick and place machine manufacturer in China, and we also provide whole line solution with peripheral devices as stencil printer, conveyor, glue dispenser, transitional and reflow oven etc.
Packages
As for the package of the machine, we put it in film packing and foam cotton, to prevent the dust and water of protecting the machine and keep dry of the machine during transportation, and equip with wooden boxes to transport to the specified port.
FAQ
1. What PCB sizes does this pick and place machine support?
This machine supports PCB sizes ranging from a maximum of 500×300mm to a minimum of 50×50mm, making it suitable for various production needs.
2. What are the main features of this SMT machine?
It features a Dual Gantry system, 20 spindles, and supports optional IC Tray and ANC system, enabling flexible production and multiple placement modes to meet different manufacturing requirements.
3. Does the machine support software upgrades? Are they free?
Yes, the machine supports free software upgrades, ensuring users receive the latest features and optimizations to enhance production efficiency.
4.What types of components can this machine place?
The machine supports a wide range of components, including 0201, ICs, BGAs, QFPs, and more. With the optional IC Tray, it efficiently handles complex package components.
