Technical Paremeter
| PCB Size |
500*450mm |
| heads |
10PCS |
| Feeder station |
52PCS |
| Components |
0201~15MM packaging material and IC material(Optional fixed camera for 0201~35*35MM), Other component size can be customized |
| X,Y,Z Axis Drive way |
High-end magnetic linear motor |
| Mounting Speed |
48000 CPH(Under best condition) |
ProductsFeatures
Head Flight Vision recognition Camera
Components with size less than 10mm high-speed and high-precision identification.
●Mark recognition:High-precision Mark recognition system,adopt
3 color illumination recognition. apply to any shape Mark and
LENS(Blu-ray scan),wider range of applications.
●Fixed flight vision camera:High-speed flight vision camera,quickly captures multiple head images at once, perform visual calibration of image position,alignment correction,adjustable light source
Ultra-high-speed Capability
Adopt High-end magnetic linear motor + servo system and multi function modular
head, the capacity increased by 25% compared with traditional machine,
optimum placement speed reach 45000 CPH.
High-speed Multi Modular Head
Adopt High-speed multi modular head,apply to ultra small chip 0201-10mm
large Chip.wider component range.
Company Profile
ETON is China’s largest manufacturer of SMT machine, industrial park more than 50000 square meters.
ETON got more than 14 years R&D experience in SMT industry equipped with core technology
ETON Got large more than 80% big led lighting industry market, machine hot sell to more than 20 countries.
ETON R&D Chinese first automatic stencil printer machine for roll to roll 100 m led strip light
ETON R&D super high speed pick and place machine, 250000 CPH, fastest in all over the world
After-services
※ Maintenance period 1year
One year warranty, during warranty, any parts need to be repaired and replaced will be free.
※ Software and hardware lifetime maintenance
Free upgrade software, software is Reach and develop by ETON, so we support whole lifetime free upgrade updates.
※ Visit customers regularly and gather information
Visit clients regularly. We attend different exhibition in different cities every year, at the same time, we will visit local clients and support our service and collect and feedback customer suggestions in time.
※ Provide latest information about technology and equipment
We give professional technology suggestion with our clients.And share the updates news to our clients
Package&Shipping
Package: Standard export package(Wooden case with vacuum package)
Step 1: Packing in film package to prevent dust and water to the machine
Step 2: Packing in foam cotton to protect the outside of the machine
Step 3: Packing in vacuum package to keep dry of the machine during transportation
Step 4: Transportation by truck to specified port
Shipping: Shenzhen port within 15 days after payment
