Detailed Product Description
Dimension(mm): 1455*800*1200 PCB Size(mm): 80*50-330*250
Size Of Turnover Frame(mm): 355*320*565 Transport Height: 900±20mm
Transport Direction: Left-Right; Right-Left Send Board Time: About 6 Seconds
High Light:

250mm Smt Handling Magazine Loader


250mm smt magazine loader


250mm Fully Automatic Smt Loader

250mm Smt Handling Magazine Loader Fully Automatic Smt Loader




This equipment is usded for the board loading operation of the circuit board in the production line


The features of machine


1.The device of loading PCB in the SMT production line;
2.PLC control, color man-machine interface operation;
3.Adopting the structure of stepping motor to push the board;
4.Auxiliary positioning brake system;
5.Multiple electrical distribution circuit protection;


Technical parameter

Product name

Automatic loader





PCB size(mm)


Size of turnover frame(mm)


Transport height


Transport direction

Left-Right; Right-Left


Around 140

PCB Thickness


Frame change time

About 25 Seconds

Send board time

About 6 Seconds


250mm Smt Handling Magazine Loader Fully Automatic Smt Loader 0

Work principle


1. The empty frame reaches the lifting platform through the frame entry track below, and then the sensor confirms the position of the material frame;

2. The stepping motor on the PCB conveying track controls the pusher to push out the PCB in the material frame;

3. The sensor feels that the PCB board is out of the frame, and the material frame will adjust the position of the material frame for the next PCB board out of the frame through the lifting platform;

4. Until the material frame is empty, the sensor senses that the material frame is empty, and the lifting platform will send the empty material frame to the upper exit rail.


ETON loader PK other company loader



loader Comparison Table



ETON Loader

Other company loader

Touch screen

7 inches

4.3 inches

Bleed valve


Not equipped


 Excellent services


1. We provide fulL SMT solution for you;
2. We provide core technology with our equipments;
3. We provide the most professional tech service;
4. We have wealthy experience on SMT factory setup;
5. We can solve any question about SMT.
