High Efficiency LED Light Making Machine Bulb SMT Pick And Place Machine

Large Image : High Efficiency LED Light Making Machine Bulb SMT Pick And Place Machine

Product Details:

Place of Origin:	CHINA
Brand Name:	ETON
Certification:	ccc,ce,risa
Model Number:	HT-E8S
Document:	Product Brochure PDF

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	FOB USD 49000~59000/sets
Packaging Details:	Our packing is made of wooden box with vacuum package, and we promise to deliver the goods within four weeks after payment.
Delivery Time:	30 work days after deposit
Payment Terms:	T/T, L/C
Supply Ability:	50 sets per mouth

Contact Now

Detailed Product Description

Dimension:	255016501550mm	Total Weight:	1250kg
System:	Windows7	Software:	R&D Independently
Power Consumption:	4KW	Feeders:	30 PCS
Nozzles:	8PCS	Speed:	40000CPH
Warranty:	1 Year	Application:	PCB, Power Driver.electric Board.lens.linear Bulb.household Appliance Etc.
Highlight:	Single module led light making machine , Windows 7 led light making machine , SMT pick and place machine 4 KW

High Efficiency led light making machine bulb pick and place machine in SMT line

Product presentation

Single module machine
Mounting components:LED,capacitors,resistors,IC,shaped components,etc.
Component:min.size 0402 max.height 36 mm.
Application: power driver.electric board.lens.linear bulb.household appliance etc.

technical parameter

HT-E8S
PCB	PCB length width	Max:1200300mm min:100100mm
	PCB thickness	0.5~5mm
	PCB clamping	Adjustable pressure pneumatic
	Mounting mode	ØGroup to picking and separate to placing ØSeparate to picking and separate to placing
O.S.	system	Windows 7
	software	R&D independently
	display	Touch screen monitor
	Input device	Keyboard , mouse
Vision system	No.of camera	2sets of imported camera Vision for the alignment identification,mark correction
	Mounting precision	0.02mm(repeat precision)
	Mounting height	<36mm
	Mounting speed	40000CPH
	Components space	0.2mm
	No.of feeders station	30PCS
	No.of nozzles	8PCS
	Power	380AC 50HZ
	Power consumption	4KW
	Conveyor transmission	Max length:1200mm
	Transmission speed	>500mm/sec
	Transmission direction	Both direction
	Transmission mode	Auto online drive
	Air pressure	>5.0kg /cm²
	Electrical control	Independent research and development by ETON
	Motion control card module 1set	Independent research and development by ETON
	X,Y,X axis drive way	Servo motor control for X,Y,Z axis
	Feeding way	Electric feeder with double motor

High Efficiency LED Light Making Machine Bulb SMT Pick And Place Machine 0

Application

Power driver,electric board,lens,linear bulb,household appliance etc.

High Efficiency LED Light Making Machine Bulb SMT Pick And Place Machine 1

Packaging & Delivery

Our mode of transportation including water, land and air transportation.You can choose the most suitable way according to your requirements.

Our packing is made of wooden box with vacuum package, and we promise to deliver the goods within four weeks after payment.

High Efficiency LED Light Making Machine Bulb SMT Pick And Place Machine 2

Certificate and Cooperators

We have many excellent overseas customers and maintain long-term cooperative relationship. Customers are very satisfied with our products.

High Efficiency LED Light Making Machine Bulb SMT Pick And Place Machine 3

Remarks

1.Payment terms: Deposit 30% in advance,the balance 70% should be paid before shipment by T/T.

2.Delivery time: 30 days after deposit.

3.Warranty: 1 year.(including spare parts)

FAQ:
Q1: We don't have any machine operation experience, is it difficult to operate?
A: Our machine is very simple! Adjustable bilingual (Chinese-English) interface, easy to learn, the operator can control the machine within 3-5 general training.
Q2: What machine can I buy from you?
Multi-function placement machine, high-speed placement machine, dispensing machine, loading machine, printing machine, reflow soldering, etc.
Q3:Do you have any customers in India? How many machines are there in India?
Yes, we have many big clients in India, such as RK, SURYA, FIEM, CALCOM, POLYCRB, etc. We have sold over a hundred machines to India and we go to the exhibition every year.
Q4:Can I visit the production site of your machines in India?
I have to ask my clients. After all, this is our customer’s factory, we can’t make decisions for my clients. I think that you wouldn’t want your competitors to visit your manufacturing site, please understand.
